Dimensions | Width | 1,461 mm (57-1/2″) (Polished finish: 1,466 mm (57-11/16″)) |
Height | 967 mm (38-1/16″) (Polished finish: 970 mm (38-3/16″)) |
Depth | 465 mm (18-5/16″) (Polished finish: 465 mm (18-5/16″)) |
Weight | Weight | 69.0 kg (152 lb, 2 oz) (Polished finish: 71.0 kg (156 lb, 8 oz)] |
Keyboard | Number of Keys | 88 |
Type | GrandTouch Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement |
Touch Sensitivity | Hard2/Hard1/Medium/Soft1/Soft2/Fixed |
88-key Linear Graded Hammers | Yes |
Counterweight | – |
Pedal | Number of Pedals | 3 |
Half Pedal | Yes |
Functions | Sustain (Switch), Sustain Contin uously, Sostenuto, Soft, Expression, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause |
GP Response Damper Pedal | Yes |
Display | Type | Full Dots LCD |
Size | 128 x 64 dots |
Language | English, Japanese |
Panel | Language | English |
Key Cover | Key Cover Style | Sliding |
Music Rest | Yes |
Music Braces | Yes |
Tone Generation | Piano Sound | Yamaha CFX, Bösendorfer Imperial, CFX Binaural Sampling |
Binaural Sampling | Yes (CFX Grand Voice only) |
Key-off Samples | Yes |
Smooth Release | Yes |
VRM | Yes |
String Resonance | – |
Damper Resonance | – |
Polyphony | Number of Polyphony (Max.) | 256 |
Preset | Number of Voices | 36 |
Compatibility | – |
Types | Reverb | 6 |
Chorus | 3 |
Brilliance | 7 |
Master Effect | 11 |
Intelligent Acoustic Control (IAC) | Yes |
Stereophonic Optimizer | Yes |
Functions | Dual/Layers | Yes |
Split | Yes |
Duo | Yes |
Preset | Number of Preset Songs | 19 Voice Demo Songs + 50 Classics + 303 Lesson Songs |
Recording | Number of Songs | 250 |
Number of Tracks | 16 |
Data Capacity | Approx. 500KB/Song |
Compatible Data Format | Playback | SMF (Format 0, Format 1) |
Recording | SMF (Format 0) |
Piano Room | Yes |
USB Audio Recorder | Playback | .wav (44.1 kHz sample rate, 16-bit resolution, stereo) |
Recording | .wav (44.1 kHz sample rate, 16-bit resolution, stereo) |
Overall Controls | Metronome | Yes |
Tempo Range | 5 ‒ 500 |
Transpose | -12 ‒ 0 ‒ +12 |
Tuning | 414.8 ‒ 440.0 – 466.8 Hz (approx. 0.2 Hz increments) |
Scale Type | 7 types |
Other Control | Tuning, Scale Type, etc. |
Rhythm | 20 |
Bluetooth | Yes |
Storage | Internal Memory | Total maximum size approx. 1.5 MB |
External Drives | USB flash drive |
Connectivity | Headphones | Standard stereo phone jack (x 2) |
MIDI | [IN] [OUT] [THRU] |
AUX IN | Stereo Mini |
AUX OUT | [L/L+R] [R] |
AUX Pedal | – |
USB TO DEVICE | Yes |
USB TO HOST | Yes |
DC IN | – |
Amplifiers | (35 W + 50 W + 20 W) x 2 |
Speakers | (16 cm + 8 cm + 5 cm) x 2 |
Acoustic Optimizer | Yes |
Power Consumption | Power consumption is described on or near the name plate, which is at the bottom of the unit. |
Auto Power Off | Yes |
Power Supply | Adaptors | – |
Accessories | Owner’s Manual, Warranty*, “50 Classical Music Masterpieces” Music Book, Online Member Product Registration, Bench*, Power cord *May not be included depending on your area. Check with your Yamaha dealer. |
